2/16
INDEX
SAFETY INFORMATION AND WARNINGS 3
PRODUCT INSTALLATION 4
POWER SUPPLY CONNECTION 5
DMX CONTROL CONNECTION 5
DMX TERMINATOR 6
PRODUCT FUNCTION SETUP 6
DMX START ADDRESS SETUP 6
STAND-ALONE MODE 7
MASTER/SLAVE MODE 7
OPERATION MENU 8
DMX PROTOCOL 9
DISPLAY INFORMATION 10
MAINTENANCE 10
PRODUCT CLEANING 11
TROUBLESHOOTING 11
TECHNICAL DATA 11
COMPONENT ORDER CODES 14
CIRCUIT DIAGRAM 15
Every ex-company fixture is tested completely and packed properly by the manufacturer. The use explanations and warnings in this
manual must be strictly followed .Any damage caused by improper use will not be covered by the manufacturer and / or dealer.
If any technical data changes, further notice won’t be offered.
ACCESSORIES
These items are packed together with the product, please check them:
Name Quantity Unit Remark
XLR signal cable 1 PCS With plug and socket
Safety cord 1 PCS
This manual 1 PCS
G clamp 1 PCS Standard
Ω clamp 1 PCS Optional
FROST BOARD 1 PCS
