Front Shock Stay
B5
Part Bags used.
Note the direction. True-to-scale diagram.
Front Shock Stay
B5
BAG
B
BAG
B
B6 Front Upper Turnbuckle Assembly
66400066
50mm
50mm Turnbuckle Rods
67410026
2
4
Shock Ball End&Spring Cupset&Rod End
29.5
mm
66400066
One side is reverse threaded.
31.3mm
Assemble in the
specified order.
M4.8x6mm Ball Studs
2
M3x10mm Flat Head Screw
2
M3X12mm Button Head Hex Screw
6
M3X18mm Button Head Hex Screw
2
M3X12mm
82400036
M3X10mm
82400106
1
M3X12mm
2
M4.8X6mm
69000040
69400046
M3
83480026
M3X18mm
80400196
M3X12mm
80400206
25
67400106
3
組裝前車殼柱時,
請注意斜面貼近前避震板
M3x12mm Flat Head Screw
2
68430036
Hole 1
4
M3 Lock Nut
83480026
2
69400016(2021)
When install front body mount,
please notice inclined
plane close to
front shock tower.
08
To Next Page
