Part Bags used.
Assemble left and right
sides the same way.
Battery Column
C2
Assemble as many times as
specified (here:twice).
BAG
C
BAG
C
Rear Hub & CVD
C3
66410036(82.50mm)
66401096
2x9.8mm
66410016
2x10.8mm
5X13X4mm
89430020
10X15X4mm
89430030
66400046
10X15mm Ball Bearing
2
5X13mm Ball Bearing
2
12X8mm-Plastic
67400166-2
M3X20mm Set Screw
2
M3X20mm
87400086
請以照電池位置不同,將M3X20mm止付螺絲前後調整
Please according to the battery difference, adjust the
M3XM20mm set screw front and rear.
11
