PR RACING VB-10 - PR VB-10 龜殼 說明書-內頁-07

Front Spindle[Right Side]
B3
Front Suspension[Left Side]
B4
3X27.80mm
M2.5x4x5.5mm
80400016
Please modify elasticity
by this screw.
For swing arm smooth
Please modify elasticity
by this screw.
For swing arm smooth
80400016
M2.5x4x5.5mm
2
2
79400106
3x27.8mm Pin
BAG
B
07
y
M2.5x4x5.5mm
66400046
M4.8X6mm
66401036
(For SC201)
67400046
66400046
66400766
2X10.8mm
79400016
1
4
2
3
5X10X4mm
Steering Screw Stepped
66401686
66401686
4
M4.8X10mm
68410066
4mm-Plastic
M4.8mmx6mm Ball Studs-68430036
M4.8x10mm Ball Studs
1
- 68430076
-66401686Steering Screw Stepped
2
1
2
89430010
5x10x4mm ZZ Ball Bearing
BAG
B
12X8mm-Plastic
67400166-2
