PR RACING VB-10 - PR VB-10 龜殼 說明書-內頁-03

Part Bags used.
Assemble left and right
sides the same way.
BAG
A
Chassis Guard Installation
A1
Servo saver
A2
Tighten securely.
BAG
A
69400086
03
2
M4.8X6mm Ball Studs
68430036
1
M3X10mm Button Head Cap Screw
80400046
M4.8X6mm Ball Studs
M3x10mm
2019-68480036
2019-68480036
66000020-2
M3x8mm Flat Head HexScrew
82400026
12
M3X8mm
M3X8mm
M3X8mm
M3X8mm
M3X8mm
M3X10mm
M3x10mm Flat Head HexScrew
82400106
4
69400066(L/R)
M3X10mm
66401306
鎖緊退回半圈
