PR RACING VB-10 - PR VB-10 龜殼 說明書-內頁-12

Part Bags used.
Rear Hub
C4
BAG
C
BAG
C
M2.5x4x5.5mm Button Head Hex Screw
80400016
3x36.8mm pin-66430110
2
2
67400036
3x36.80mm
M2.5x4x5.5mm
1.85mm
Fornt
上孔
TOP hole
車頭
2
1
M3X8mm Flat Head Hex Screw
4
3X8X0.15mm Washer
2
82400026
M3X8mm
85440320
2
3X47.5mm-66430120
66000020-3
66000020-4
66400566
3X8X0.15mm
85440320
68410066
Please add it or not
according to the loose-tight.
依據鬆緊，請加它或不加它。
3x47.5mm
M3X8mm
Rea Suspension Mount
C5
Assemble left and right
sides the same way.
L
12
