Rear Body Mount Set
D3
BAG
F
M3X14mm Button Head Hex Screw
2
M3X15mm Flat Head Hex Screw
2
80400056
82400176
2
2
M3x15 mm Flat Head Screws
82400176
66401806-Ball Joint
77430066-55mm Turnbuckles
One side is reverse
threaded.
M3X15mm
66401806
One side is reverse threaded.
38.5 mm
66400066
67410036
55mm
2
2
M3x10 mm Flat Head Screws
82400106
Assemble in the
specified order.
4
48mm
Part Bags used.
69400016(2021)
66400106
M3X14mm
組裝車殼柱時
請注意將平面貼近避震板
When install front body
mount,please notice plane
close to front shock tower.
Front
15
M3X15mm
M3X10mm
1MM
