Part Bags used.
Assemble left and right
sides the same way.
Note the direction.
One side is reverse threaded.
BAG
B
BAG
C
Turnbuckle Assembly-Steering Rod
B8
Rear Chassis Brace (Mid Motor)
C1
L
R
L
R
2
Rod End-R-66400066
1
1
2
50mm Turnbuckle Rods-67410026
Rod End-L-66400066
Rod End 31.3mm-664000660
M3X18mmFlat Head Hea Screw
2
M3X25mm Button Head Hex Screw
4
M3X18mm
82400126
M3X25mm
80400076
69400016
66400056
10
31.3mm
34.2
mm
34.2
mm
