PM-833TV
FAQ
R8 collets won’t go
into the spindle
The collet locating screw could be
in too far. See the end of Section 4,
Maintenance, for special instruc-
tions on this.
This means that R8 devices are
not properly clamped. There are
two options:
1. Insert a 1/2" or 12 mm (clear-
ance) ID collar under the cap to
ll the gap.
2. Shorten the drawbar, see the
end of Section 4, Maintenance.
The drawbar cap doesn't
seat on the spindle
Motor switch turned ON,
but motor doesn't run
220 Vac power connected?
E-Stop button pressed in?
(Release it by turning clock-
wise)
Fuses good?
