This input allows you to add remote that will allow you to control the subwoofer output of
your ATOM amplifier from your dashboard. and to adapt the amplifier to all kind of signal
sources with varying levels there are a level control provided on the amplifier next to the
phone jacks. It should not be used as volume controls. Start with a "12’ clock" setting of
the level controls. If you set the head unit volume to 75% of maximum you should achieve a
good sound without distortion. Find a point of the level setting where the distortion is just
discernible. At this point slightly reduce the control.
REMOTE SUBWOOFER LEVEL CONTROL
HOW TO INSTALLATION
The dash control mounts with two screws, which attach to the underside of the dashboard.
Slide under the dash and place the dash control in its mounting position, mark the two
mounting holes, drill pilot holes, and secure with two screws.
