Precision Power ATOM Series - MPA700.4 D Specifications

4
A700.4D
FUSES
POWER INPUT
+ L - G - R +
+ L - G - R +
AUTO TURN ON
FRONT
AUTO TURN ON
REAR
FRONTREAR
HI-INPUT
HI-INPUT
L
R
THRU-OUT
L
R
REM
GND
DC12V
REAR
BRIDGED MODE
FRONT
BRIDGED MODE
20A 20A
SPEAKERS OUT
8 9 10 11 7 7 2 4 1 2
FULL
LPF
HPF
6.0V ~ 0.25V
GAIN
FRONT
50Hz ~ 500Hz
X-OVER GAIN
6.0V ~ 0.25V
REAR
FULL
LPF
HPF
50Hz ~ 500Hz
X-OVER
0dB ~ 18dB
BASS BOOST
at 45Hz
MPA700.4D
13 19 15 13 19 15
18 18
16
4 CHANNELS CLASS D PREMIUM AUDIO SYSTEM
MPA700.4D
ADDITIONAL SPECIFICATIONS
•100w x 4 @ 4-ohm Stereo
•175w x 4 @ 2-ohm Stereo
•350w x 2 @ 4-ohm Bridged
•1,400w MAX Power
•Variable 50-500Hz 12dB High Pass Filter
•Variable 50-500Hz 12dB Low Pass Filter
•Variable 0-18dB 45Hz Bass Boost
•Total Harmonic Distortion: 0.05% @ 4-ohm
•Frequency Response: 20- +20KHz
•Signal-to-Noise Ratio: 90dB
•Channel Separation: ≤55dB
•Input Sensitivity: 250mV-6V
•Dimensions: 6"w x 2.25"h x 10"l
