Precision Power ATOM Series - MPA1000.5 D Specifications

ADDITIONAL SPECIFICATIONS
5
MPA1000.5D
6.0V ~ 0.25V
GAIN GAIN
50Hz ~ 500Hz
FULL
LPF
HPF
X-OVER
6.0V ~ 0.25V
50Hz ~ 500Hz
X-OVER
OFF ON
SUM
6.0V ~ 0.25V
20Hz ~ 50Hz
GAIN
SUB SONIC
0° 180°
0dB ~ 18dB
50Hz ~ 500Hz
PHASE SHIFT BASS BOOST
LOW PASS
at 45Hz
FRONT
FULL
LPF
HPF
REAR SUB
5 CHANNELS CLASS D PREMIUM AUDIO SYSTEM
13 19 15 13
19
15
1818
20 13 14 3 17 16
A1000.5D
FUSES
POWER INPUT
REAR
BRIDGED MODE
FRONT
REM
GND
DC12V
SUB WOOFER
BRIDGED MODE
+ L - G - R +
AUTO TURN ON
FRONT
+ L - G - R +
AUTO TURN ON
REAR
SUB
HI-INPUTHI-INPUT
REAR FRONT
AUTO TURN ON
+ L - G - R +
SUB
L
R
GAIN CONTROL
L
R
20A 20A 20A
SPEAKERS OUT
REMOTE
8 9 10 11 8 7 7 6 2 1 2
MPA1000.5D
•60w x 4 (4-ohm Stereo) + 250w x 1 (4-ohm Mono)
•100w x 4 (2-ohm Stereo) +450w x 1 (2-ohm Mono)
•200w x 2 (4-ohm Bridged) + 450w x 1 (2-ohm Mono)
•2,000w Combined MAX Power
•Variable 50-500Hz 12dB High Pass Filter (chs. 1-4)
•Variable 50-500Hz 12dB Low Pass Filter (chs. 1-5)
•Variable 20-50Hz 12dB Subsonic Filter (ch. 5)
•Selectable 0-180。Phase Switch (ch. 5)
•Variable 0-18dB 45Hz Bass Boost (ch. 5)
•Total Harmonic Distortion: 0.05% @ 4-ohm
•Frequency Response: 20- +20KHz
•Signal-to-Noise Ratio: 90dB
•Channel Separation: ≤55dB
•Input Sensitivity: 250mV-6V
•Dimensions: 6"w x 2.25"h x 13.25"l
