6
ADDITIONAL SPECIFICATIONS
A1200.1D
FUSES
POWER INPUT
MASTER
INPUT
HI-INPUT
DTAT LINK
AUTO TURN ON
+ L - G - R +
REM
GND
DC12V
L
R
GAIN CONTROL
20A
20A
20A
20A
SPEAKERS OUT
REMOTE
SLAVE
8 9 10 11 7 7 6 7 1 2
6.0V ~ 0.25V
20Hz ~ 50Hz
0° 180°
0dB ~ 18dB
MASTER SLAVE
50Hz ~ 500Hz
MPA1200.1D
GAIN
SUB SONIC
PHASE SHIFT BASS BOOST
LOW PASS
DATA LINK
at 45Hz
MONO CHANNEL CLASS D PREMIUM AUDIO SYSTEM
13 14 3 16 15 5
MPA1200.1D
•400w x 1 @ 4-ohm Mono
•700w x 1 @ 2-ohm Mono
•1,200w x 1 @ 1-ohm Mono
•2,400w MAX Power
•Variable 50-500Hz 12dB Low Pass Filter
•Variable 20-50Hz 12dB Subsonic Filter
•Selectable 0-180。Phase Switch
•Variable 0-18dB 45Hz Bass Boost
•Total Harmonic Distortion: 0.3% @ 4-ohm
•Frequency Response: 20 - 500Hz
•Signal-to-Noise Ratio: 90dB
•Input Sensitivity: 250mV-6V
•Dimensions: 6"w x 2.25"h x 10"l
