Part# Color Ga Length From Conn. ToConn. From Location To Location
1 330286 BLK/WHT 18 FULL 72" PLUG F250 #18-#22 TRANSFORMER TERMINAL BLOCK (LH TAB)
2 330296 BLK 18 FULL 72" PLUG F250 #18-#22 TRANSFORMER TERMINAL BLOCK (RH TAB)
3 WHT 16 26" F250 #14-#16 PIGG #14-#16 TERMINAL BLOCK (RH TAB) RELAY A
4 BLK 16 12" F250 #14-#16 F250 #14-#16 TERMINAL BLOCK (LH TAB) STOP SWITCH COM
5 RED 16 20" F250 #14-#16 F250 #14-#16 TERMINAL BLOCK (LH TAB) RINSE SWITCH WHITE COM
6 RED 16 14 F250 #14-#16 BARE TERMINAL BLOCK (LH TAB) TIMER BASE 3
7 064026 BLK 16 96" F250 #14-#16 F250 #14-#16 TERMINAL BLOCK (RH TAB) RINSE SOLENOID VALVE
8 BLU 16 8" BARE BARE TIMER BASE 6 TIMER BASE 7
9 RED 16 8" BARE BARE TIMER BASE 2 TIMER BASE 3
10 BRN 16 14" BARE PIGG #14-#16 TIMER BASE 1 HEAD SOLENOID VALVE A
11 WHT 16 14" BARE PIGG #14-#16 TIMER BASE 8 HEAD SOLENOID VALVE B
12 BLK 16 10" BARE F250 #14-#16 TIMER BASE 8 STOP SWITCH NC
13 BLU 16 12" BARE F250 #14-#16 TIMER BASE 8 START SWITCH NO
14 BLU 16 12" BARE F250 #14-#16 TIMER BASE 7 START SWITCH COM
15 ORG 16 9" PIGG #14-#16 F250 #14-#16 HEAD SOLENOID B START SWITCH LIGHT TOP TAB
16 ORG 16 9" PIGG #14-#16 F250 #14-#16 HEAD SOLENOID A START SWITCH LIGHT BOTTOM TAB
17 WHT 16 24" F250 #14-#16 F250 #14-#16 HEAD SOLENOID B RELAY 1
18 BRN 16 24" F250 #14-#16 F250 #14-#16 HEAD SOLENOID A RELAY 3
19 WHT 16 3" F250 #14-#16 F250 #14-#16 RELAY A RELAY 4
20 WHT 16 3" PIGG #14-#16 F250 #14-#16 RELAY B RELAY 6
21 BRN 16 26" F250 #14-#16 PIGG #14-#16 RELAY B RINSE SWITCH WHITE NO
22 WHT 16 8" F250 #14-#16 FPIN RELAY 7 PUMP RECEPTACLE 1
23 BRN 16 22" F250 #14-#16 FPIN RELAY 9 PUMP RECEPTACLE 2
24 064026 BRN 16 96" F250 #14-#16 F250 #14-#16 RINSE SWITCH WHITE NO RINSE SOLENOID VALVE
25 080377 BLK 18 FULL 72" F250 #18-#22 PLUG RINSE SWITCH BLACK COM OZONE GENERATOR
26 080377 BLK 18 FULL 72" F250 #18-#22 PLUG RINSE SWITCH BLACK NO OZONE GENERATOR
2. #25 & #26 WIRES ARE ATTACHED TO THE OZONE GENERATOR PLUG.
3. #7 & #24 WIRES ARE 6 CONDUCTORS CABLE, ONLY 2 ARE USED ON
TOP TO BOTTOM (RED, WHITE, GREEN & BLUE WIRES ARE NOT USED).
TOP END STRIP SHEATH 32" AND LOCK @ GROMMENT 34" WITH TIE STRAP.
BOTTOM END STRIP SHEATH 18".
