Precision 0002 Series User Manual

19
SERIES 1
No.
Part# Color Ga Length From Conn. ToConn. From Location To Location
1 330286 BLK/WHT 18 FULL 72" F250 #18-#22 TRANSFORMER TERMINAL BLOCK (RH TAB)
2 330296 BLK 18 FULL 72" F250 #18-#22 TRANSFORMER TERMINAL BLOCK (LH TAB)
3 WHT 16 26" F250 #14-#16 PIGG #14-#16 TERMINAL BLOCK (RH TAB) RELAY A (LH)
4 BLK 16 12" F250 #14-#16 F250 #14-#16 TERMINAL BLOCK (LH TAB) STOP SWITCH COM (LH)
5 YLW 16 26" F250 #14-#16 PIGG #14-#16 TERMINAL BLOCK (RH TAB) RELAY A (RH)
6 RED 16 20" F250 #14-#16 F250 #14-#16 TERMINAL BLOCK (LH TAB) RINSE SWITCH WHITE COM (LH)
7 RED 16 10" F250 #14-#16 BARE TERMINAL BLOCK (RH TAB) TIMER BASE 3 (LH)
8 BLK 16 12" F250 #14-#16 F250 #14-#16 TERMINAL BLOCK (LH TAB) STOP SWITCH COM (RH)
9 RED 16 10" F250 #14-#16 BARE TERMINAL BLOCK (RH TAB) TIMER BASE 3 (RH)
10 GRN 16 20" F250 #14-#16 F250 #14-#16 TERMINAL BLOCK (LH TAB) RINSE SWITCH WHITE COM (RH)
11 064026 BLK 16 96" F250 #14-#16 F250 #14-#16 TERMINAL BLOCK (RH TAB) RINSE SOLENOID VALVE (LH)
12 BLU 16 8" BARE BARE TIMER BASE 6 (LH) TIMER BASE 7 (LH)
13 064026 BRN 16 96" F250 #14-#16 F250 #14-#16 TERMINAL BLOCK (RH TAB) RINSE SOLENOID VALVE (RH)
14 RED 16 8" BARE BARE TIMER BASE 2 (LH) TIMER BASE 3 (LH)
15 BLU 16 8" BARE BARE TIMER BASE 6 (RH) TIMER BASE 7 (RH)
16 BRN 16 14" BARE PIGG #14-#16 TIMER BASE 1 (LH) HEAD SOLENOID VALVE A (LH)
17 RED 16 8" BARE BARE TIMER BASE 2 (RH) TIMER BASE 3 (RH)
18 WHT 16 14" BARE PIGG #14-#16 TIMER BASE 8 (LH) HEAD SOLENOID VALVE B (LH)
19 BLU 16 14" BARE PIGG #14-#16 TIMER BASE 1 (RH) HEAD SOLENOID VALVE A (RH)
20 BLK 16 10" BARE F250 #14-#16 TIMER BASE 8 (LH) STOP SWITCH NC (LH)
21 YLW 16 14" BARE PIGG #14-#16 TIMER BASE 8 (RH) HEAD SOLENOID VALVE B (RH)
22 BLU 16 12" BARE F250 #14-#16 TIMER BASE 8 (LH) START SWITCH NO (LH)
23 BLK 16 10" BARE F250 #14-#16 TIMER BASE 8 (RH) STOP SWITCH NC (RH)
24 BLU 16 12" BARE F250 #14-#16 TIMER BASE 7 (LH) START SWITCH COM (LH)
25 BLU 16 12" BARE F250 #14-#16 TIMER BASE 8 (RH) START SWITCH NO (RH)
26 ORG 16 9" PIGG #14-#16 F250 #14-#16 HEAD SOLENOID B (LH) START SWITCH LIGHT BOTTOM TAB (LH)
27 BLU 16 12" BARE F250 #14-#16 TIMER BASE 7 (RH) START SWITCH COM (RH)
28 ORG 16 9" PIGG #14-#16 F250 #14-#16 HEAD SOLENOID A (LH) START SWITCH LIGHT TOP TAB (LH)
29 ORG 16 9" PIGG #14-#16 F250 #14-#16 HEAD SOLENOID B (RH) START SWITCH LIGHT BOTTOM TAB (RH)
30 WHT 16 24" F250 #14-#16 F250 #14-#16 HEAD SOLENOID B (LH) RELAY 1 (LH)
31 ORG 16 9" PIGG #14-#16 F250 #14-#16 HEAD SOLENOID A (RH) START SWITCH LIGHT TOP TAB (RH)
32 BRN 16 24" F250 #14-#16 F250 #14-#16 HEAD SOLENOID A (LH) RELAY 3 (LH)
33 YLW 16 24" F250 #14-#16 F250 #14-#16 HEAD SOLENOID B (RH) RELAY 1 (RH)
34 WHT 16 3" F250 #14-#16 F250 #14-#16 RELAY A (LH) RELAY 4 (LH)
35 BLU 16 24" F250 #14-#16 F250 #14-#16 HEAD SOLENOID VALVE A (RH) RELAY 3 (RH)
36 WHT 16 3" PIGG #14-#16 F250 #14-#16 RELAY B (LH) RELAY 6 (LH)
37 WHT 16 3" F250 #14-#16 F250 #14-#16 RELAY A (RH) RELAY 4 (RH)
38 BRN 16 26" F250 #14-#16 PIGG #14-#16 RELAY B (LH) RINSE SWITCH WHITE NO (LH)
39 WHT 16 3" PIGG #14-#16 F250 #14-#16 RELAY B (RH) RELAY 6 (RH)
40 WHT 16 8" F250 #14-#16 FPIN RELAY 7 (LH) PUMP RECEPTACLE 1
41 BLU 16 26" F250 #14-#16 PIGG #14-#16 RELAY B (RH) RINSE SWITCH WHITE NO (RH)
42 BRN 16 26" F250 #14-#16 FPIN RELAY 9 (LH) PUMP RECEPTACLE 2
43 BLU 16 8" F250 #14-#16 FPIN RELAY 7 (RH) PUMP RECEPTACLE 7
44 064026 BRN 16 96" F250 #14-#16 F250 #14-#16 RINSE SWITCH WHITE NO (LH) RINSE SOLENOID VALVE (LH)
45 YLW 16 8" F250 #14-#16 FPIN RELAY 9 (RH) PUMP RECEPTACLE 6
46 WHT 16 24" PIGG #18-#22 F250 #18-#22 RINSE SWITCH BLACK NO (LH) RINSE SWITCH BLACK NO (RH)
47 064026 BLU 16 96" F250 #14-#16 F250 #14-#16 RINSE SWITCH WHITE NO (RH) RINSE SOLENOID VALVE (RH)
48 080377 BLK 18 FULL 72" PIGG #18-#22 PLUG RINSE SWITCH BLACK COM (LH) OZONE GENERATOR
49 080377 BLK 18 FULL 72" PIGG #18-#22 PLUG RINSE SWITCH BLACK NO (LH) OZONE GENERATOR
50 BLK 16 24" F250 #18-#22 F250 #18-#22 RINSE SWITCH BLACK COM (LH) RINSE SWITCH BLACK COM (RH)
NOTES: 1. #1 & #2 WIRES ARE ATTACHED TO THE TRANSFORMER.
2. #47 & #48 WIRES ARE ATTACHED TO THE OZONE GENERATOR PLUG.
3. #11, #13, #44 & #47 WIRES ARE 6 CONDUCTORS CABLE, ONLY 4 ARE USED
ON TOP TO BOTTOM (RED & WHITE WIRES ARE NOT USED).
TOP END STRIP SHEATH 32" AND LOCK @ GROMMENT 34" WITH TIE STRAP.
BOTTOM END STRIP SHEATH 18".
Wiring List - PURELY NATURAL DOUBLE DISPENSER, BFDSA-2 PART # 330447A
Wiring List, BFDSA-2
