Photo 3
Lay upper assembly on base to
connect wiring
Connect wiring
Upright support
Base frame
Foot pedals
Support pad
7. Con nect Electronic Cable. (Photo 3) To connect the electronic cable, take
the following steps:
a. Move the foot pedals to the rear of the base frame.
b. Lift the upper assembly and upright support off the base post. Lay the
assembly on the base with the support pad resting on the foot pedals
and the upright support balanced on the base post as shown in Photo
3.
c. Locate the electronic cable in the upright support and connect it to the
wire in the base frame.
d. Gently pull the cable down the center of the base post. If the cable is
not easily accessible, use the hex key found in the hardware kit to
hook the cable and pull it within your reach.
e. Attach the cable to the cable connector protruding from the base post.
Note: The connecting cables engage in one direction only. Do not
force the connection, it should easily snap in place.
f. Tuck any excess wire into the upright support. Be careful not to pinch
or crimp the cables.
Important: Cables pinched or otherwise damaged by improper
installation will not be covered by warranty. To avoid damaging the
wires, we recommend using a second person to help guide the upper
assembly/upright support into place.
page 9
