Precor EFX534i t User Manual

page 14
COMMERCIAL PRODUCTS DIVISION
10. Connect the cable. Diagram 7, inset. Insert the cable into its receptacle.
Just like a telephone connection, a definite "click" is heard when a good
connection is made. If you do not hear a "click," try reinserting the cable
connection again.
11. Push excess cable inside base tube. Diagram 7. Carefully, push any excess
cable behind the height adjuster threads that protrude from inside the base tube.
12. Rotate the rear pads. Diagram 8, inset. Ask your assistant to stabilize the
unit while you rotate the rear adjustable pad to the highest position. This
procedure lifts the base assembly off the floor which provides better access
to the fasteners.
13. Place the base assembly on the supportive wedge. Diagram 8. Have an
assistant grasp and lift the upright support so that you can slide a wedge
(packing material) under the front of the unit.
Diagram 8 Place the base
on supportive
blocks.
Adjustable rear pad
Supportive
wedge
Base assembly

Precor EFX534i t Specifications

Frame and Construction

crossramp	20° (fixed)
frame	Powder-coated steel
regulatory approval	FCC, ETL, CE

Weight and Dimensions

length	80 inches (203 cm)
width	32 inches (81 cm)
height	64 inches (162 cm)
weight	207 lbs (94 kg)
shipping weight	255 lbs (116 kg)
stride length	18 inches (46 cm)
