Trim Side Cover Replacement
Trim Side Cover Replacement
ID Description
Trim Side Cover - left
Trim Side Cover - right
Removal Instructions
Repeat the removal procedure for both the left or right side trim covers.
1. Remove the hood cover, see "Hood Cover Replacement" on page 82.
2. Remove the trim landing cover, see "Covers and Panels Replacement" on page 80.
3. Replace the trim end caps, see "Trim End Cap Covers Replacement" on page 88.
4. Remove the hood transition cover, see "Covers and Panels Replacement" on
page 80.
5. Starting from the front moving reward, use a standard flat blade screwdriver to
release (unsnap) the top of the trim side cover from four anchor mount clips. Hold
cover while releasing the upper anchor bracket clips and then pull down and away
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 90
6 Replacement Procedures
Covers and Panels Replacement
