• Never operate the unit if it is damaged, if it is not working properly, if it
has been dropped, or dropped in water. Return the unit to a service
center for examination and repair.
• Keep the optional battery recharger cord away from heated surfaces.
• Do not operate where aerosol (spray) products are being used or where
oxygen is being administered.
• Do not use outdoors.
• Do not attempt to service the EFX yourself other than the assembly
and maintenance instructions found in this manual. Refer to
Obtaining
Service
.
HAZARDOUS MATERIALS AND PROPER DISPOSAL
The self-powered EFX has an internal battery which must be removed before the
EFX is scrapped. The battery contains materials which are considered hazardous
to the environment. Proper disposal of the battery is required by federal law.
To remove the battery from the EFX, take the following steps:
CAUTION: Unplug the battery recharger and disconnect it from
its receptacle at the rear of the EFX.
Tools required: Phillips head screwdriver and hex wrench set.
1. Remove both the right and left rear covers from the EFX.
2. Remove the top rear cover.
3. Unplug the black and red battery wires from the circuit board.
4. Separate the circuit board from the battery by removing four screws.
5. The battery is held in place with a metal bracket. Lift the battery away from
the bracket.
6. Dispose of the battery according to the federal Hazardous Waste Regulations.
SAFETY APPROVAL
When identified with the ETL-c logo, the EFX has been tested and conforms to
the requirements of CAN/CSA-E-335-1/2-94, Safety of Household and Similar
Electrical Appliances.
Diagram 1
IMPORTANT SAFETY INSTRUCTIONS
Avoid injury from the roller
arm mechanism.
Front cover
Handlebar
Lower pivot roller arm
(handlebar linkage)
Ramp
