Page 8 of 20
STEP 6
Estimated Time: 10 minutes
Attach “T” spacers to ONE side of each
inner gable with drawer slide screws
6b
IMPORTANT:
Before attaching the drawer glides, determine the
TOP and BOTTOM of each inner gable.
Check the position of the drawer glides carefully
before you attach them to the inner gables.
A. Measure from each edge of the “T” Spacer to
each unfinished edge.
B. The measurement that is approximately 4” will
be the BOTTOM.
6c
Repeat steps 6a & 6b for the 2nd side
of the inner gables.
Wheel is on the bottom and
toward finished edge
Finished
Edge
Bottom
4”
Unfinished Edge
Attach “T” spacers and drawer glides to Inner Gables
6a
Drawer Slide
Screw
Attach drawer glides to “T” spacers on
inner gables.
Position the drawer glides with:
A) The wheel at the finished edge
B) The wheel on the bottom
Drawer
Slide Screw
Bottom
4”
Top
7”
To Next Page
