Prepac SS-4824 - STEP 1: Prepare Sides and Bottom; Insert Cams into Panels; Attach Twister Dowels

Cabinet Hardware
Hardware Identification
2" Confirmat Screws
(6)
RM-0001
15mm Zinc Cam (8)
RM-0103
¾” Nail (18)
RM-0022
Screw Cover Caps (6)
RM-0226 Black
RM-0228 Espresso
RM-0008 White
Green Twister Dowel (8)
RM-0501
STEP 1
Estimated Time: 5 minutes
Insert cams into holes on left (C3) and right (C4) sides and
the unfinished side of the bottom (C5)
Make sure arrow on
cam faces hole for
connecting bolt
Plastic Dowels (10)
RM-0072
Screw green twister dowels into Left (C3) and Right (C4) Sides
C5
C3
C4
1a.
1b.
Page 3 of 12
