Pressure Systems 9022 - Page 103

Pressure Systems, Inc. NetScanner™ System (9016, 9021, & 9022) User’s Manual
ii dd
Description ‘q’ read
index
www.PressureSystems.com
3 - 73
26 00
01
(for Models 9021 and 9022 ONLY) Initialize Generic
Sensor Parameters with Factory Default Parameters on
Power-up.
Retrieve user-provided parameters out of non-volatile
memory
27 00 Store current coefficient terms into transducer’s non-
volatile memory. (For use only with non-digitally
compensated 9400 sensors with EEPROM.) (‘w27’ selects
all channels) (‘w2700 eeee’ selects individual channels via
the position field)
3C 00 (9016 only) Set Temperature Range = 0 to 60ºC default
06 Set Temperature Range = -30 to 60ºC
07 Set Temperature Range = -20 to 70C
Modification of option 13 hex results in the new option selection becoming the module’s new
power-on default. All other options must be stored in non-volatile flash memory using ‘w07’
command in order to be retained after the module power cycles.
