Pressure Systems, Inc. NetScanner™ System (9016, 9021, & 9022) User’s Manual
www.PressureSystems.com
3 - 56
Bit 6: SRAM Error.
03 reserved
04 reserved
05
Number of A/D Samples To Average, as hex value (e.g., 000A=10 decimal).
10
06
IP Address Resolution Method, as hex state: (default = 0000)
0000 = Use Static IP Address stored in module’s non-volatile memory
0001 = Get Dynamic IP Address from external RARP/BOOTP server
13
07
Host Response/Stream Back-Off Delay, as hex value (or FFFF). FFFF
means use low-order byte of module’s Ethernet Address as value instead. In
either case, back-off delay in microseconds is calculated from decimal
equivalent of hex value:
delay = decvalue * 20
14
08
Host Response/Stream Total Size Prefix (with 2-byte big-endian binary
value), added to all command responses and streams to indicate their true
length in bytes:
0000 = None (default)
0001 = Yes
16
09
TCP Connect Port, as hex value (e.g. 2328 = 9000 decimal, default).
17
0A
Auto UDP Broadcast@Reset, as hex state:
0000 = No (default)
0001 = Yes
18
0C
Temperature Status of Each Scanner Transducer (9016 only), as 16-bit hex
bit map, each bit representing the current status of a transducer/channel (16-1)).
Bit values are:
0= transducer operating within the specified operational limits.
1= transducer operating outside the specified limits.
(see end-of-table NOTE +)
0D
Minimum Temperature Alarm Set Point (9016 only)(in degrees C), as
decimal (**) format 0 representation of internal IEEE float, with leading
space).
19
0E
Maximum Temperature Alarm Set Point (9016 only)(in degrees C), as
decimal (**) format 0 representation of internal IEEE float, with leading
space).
19
