Prestige 75 - Installation Instructions; Dimensions; Installation Area and Accessibility; Wall Mounting

EN • 13
ENGLISHFRANCAISNEDERLANDSESpAñoLITALIANoDEuTSCH
664Y3300
Min. 300 mmMin. 220 mm
Min. 25 mm Min. 25 mm
prestige
- The boiler must be mounted on a non-flammable
surface.
- Drill two holes with a depth of 75 mm using a 10 mm
drill bit, following the spacing given above.
- Fasten the wall mount using the supplied lag screws.
- Attach the boiler to the wall mount.
INSTALLATION AREA
- Make sure that any ventilation openings remain clear at all
times.
- Do not store any flammable materials in this room.
- Do not store any corrosive materials, paint, solvents, salts,
chlorine products or any other detergent products in the
vicinity of this appliance.
- If you smell gas, do not turn on any lights, close the gas
valve on the meter, ventilate the rooms and contact your
installer.
101,6 mm
101,6 mm
48,4 mm
53,2 mm
53,2 mm
48,4 mm
WALL MOUNTING

The appliance must be placed in such a way that it is
always easily accessible. Furthermore, the unit must have
the following minimum clearance around it.
INSTALLATIoN INSTRuCTIoNS
A. Heating outlet 1”1/4 [M]
B. Heating return 1”1/4 [M]
C. Gas connection 3/4” [M]
A. Heating outlet 1”1/2 [M]
B. Heating return 1”1/2 [M]
PRESTIGE SOLO 120 DIMENSIONSPRESTIGE SOLO 50 - 75 DIMENSIONS
535
374 A / B
411 C
303 D
138
1000
prestige
1035
118
273
100100
632
D
C
87
A 178
397
B 549
535
374 A / B
411 C
303 D
138
1000
prestige
1035
118
273
100100
632
D
C
87
A 178
397
B 549
288
48
A / B
C
A
C
65
316
B 436
prestige
392
100
150
175
502
396
930
982
288
48
A / B
C
A
C
65
316
B 436
prestige
392
100
150
175
502
396
930
982
C. Gas connection 1” [M]
D. Connection to the 1” safety valve [M]
