1. Modulating Air/Gas premix burner
2. Manual air vent
3. Stainless steel heater body
4. Low-water-level pressure switch
5. Concentric chimney connection
Ø 100/150 mm
6. Chimney tube
7. Gas pressure switch
8. Electrical panel
9. Control panel
1. Chimney connection Ø 100 mm
2. Chimney tube
3. Auto-air vent
4. Stainless steel heater body
5. Safety valve
6. Low-water-level pressure switch
7. Air intake connection Ø 100 mm
8. Modulating Air/Gas premix burner
9. Gas valve
10. Safety thermostat
11. Electrical panel
12. Gas pressure switch
13. Control panel
1
3
4
13
11
9
7
8
6
2
5
12
10
