EN • 19
ENGLISHFRANCAISNEDERLANDSESpAñoLITALIANoDEuTSCH
664Y2300.C
Factory
setting
typical
setting Description
Factory
setting
typical
setting Description
00 : Heating mode “OFF”
01 : Heating mode “ON”
• Direct circuit : weather depending
controlled. The pump of the direct circuit
is controlled by the room thermostat.
• Mixed circuit : weather depending
controlled. The pump runs continuously.
• Mixed circuit without DHW priority :
Switch P34 to 60.
Setting T° for the heating water (adjust-
able between 30 and 85°C).
T° min. for the heating water
(adjustable between 15 and 60°C).
• Direct 2 mixed circuit : weather
depending controlled. Both pumps runs
continuously. Night setback on the direct
circuit controlled by time-clock.
• Mixed circuit without DHW priority :
Switch P34 to 61.
Minimum outside temperature [T4]
(adjustable between -20 and 10°C).
Maximum outside temperature [T4]
(adjustable between 15 and 25°C).
Booster
Maximum temperature of the
second heating circuit
Night setback (°C) only if a
time-clock is connected to 1 and 2,
and P34 is set to 21 or 61.
Minimum temperature of the second
heating circuit
N
Y1
Y2
PhPE
NN
X1
X2
X3
21
L
L1
1 2 3 4 5 6 7 8 9 10 11 12 13 1 2 3
PE
Ph
N
INSTALLATIoN
Outside T° (°C)
90
80
70
60
50
40
30
20
10
0
-20-25 -10-15 0-5 1052015 25
P4
P39
P40
P5
P6 P7
T° departure boiler (°C)
To be wired in accordance with the applicable regulations.
