11
POWER •Power supply switch, turn the AC power cord
on and off�
12
MIC IN •Connect a collect device with microphone
(Sound amplifying function)�
13
AV OUT •AudioVideo -OUT�
14
AV IN •Compound video, Audio-IN�
15
YPbPr IN •YPbPr signal input, connect DVD, set -top-box
with YPbPr�
16
AUDIO IN •Connect PC Audio from external sources�
17
VGA IN •Connect PC Image from external sources�
18
COAX OUT •Coaxial output�
19
HDMI IN •High Definition Multimedia Interface�
20
TOUCH •External PC touch signal input� The default
function can be use under the internal PC�
You can control the external computer
through this unit under the situation that
the driving has installed� (the touch function
can be available at the PC, VGA and HDMI
source)�
21
WIFI •Wireless antenna�
22
USB IN •Connect USB device, such as Hard Disk, USB
keyboard mouse etc�
23
VGA OUT •Connect the device with VGA-IN�
24
AUDIO OUT •Connect the device with Earphone-IN�
25
MIC •Connect a collect device with microphone
(Recording function)�
26
LAN IN •Standard net orifice, Connect Rj45 net
interface�
