Assembly completed. {
485(B)—11/19 — A4.4 For more wonderful cages, toys, and accessories for dogs, cats, birds, chickens, rabbits, ferrets and small animals, visit www.prevuepet.com
4
PIECES
Follow the assembly method from Step 3:
Place the side panel (L3) and the upper
back panel (B2) (no brackets) in place and
attach together with a hex screw in the
top bracket bottom hole.
Continue adding and attaching panels
[side panel (R3), upper front panel (F3)],
with hex screws in the top bracket
bottom holes.
Hook a ramp to the
underside of a platform.
Place the platform in
the lower level, on the
middle horizontal wire.
Remove the divider door. Hook a ramp on
the wire loops, and rest the other end on
the platform below. NOTE: The divider may
be replaced with the ramp installed.
At this point, go over the entire cage
and tighten up all screws until snug.
⁕
5
PIECES
interchangeable
]L
3
]R
3
]F
3
]Cr
]Ct
]B
3
× 10
Place the roof (CR) (with the
attached sliding door) in
position and attach with
a hex screw on each side.
Add the remaining
ramp and platform
in the upper level.
Add the hammock.
Rotate the windbell
lock up, to slide
the tray into place.
