Prima DV2018 - Getting Started; Front Panel Overview

Front
3
1
+C
H
+
VOLCH
MENU
STOP
PLAY
OPEN/ CLOSE TV/AV TV/DVDVOL
VIDEO L /MONO-AUDIO-R
()
2
2
3
4
5
6
7
8 9 10 11
13 14 15 16
1. AV2 inputs (VIDEO, AUDIO L/MONO, R)
2. Earphone jack
3. Open/close disc tray
4. Playback
5. Stop playback
6. Channel down select; menu item select
7. Channel up select; menu item select
8. Volume down adjust; menu item adjust
9. Volume up adjust; menu item adjust
10. Display MENU of TV
11. Video input select
12. Switch between TV/AV and DVD
13. Remote sensor
14. Power indicator (red)
15. Purple indicator
16. Power button
Disc tray
Getting Started
12
