Connect the left and right loudspeakers to the correspon-
ding terminals. The terminals can accept speaker cables
terminated with 4mm banana plugs, spade terminals, or
bare wires. To connect bare wires unscrew the terminal,
pass the bare wire through the hole in the terminal bolt,
and clamp the wire in place by screwing the terminal back
The PRE OUT sockets provide a line-level output from
the I21 preampli er stage which can be connected to
another preampli er. The level of this output is controlled
by the VOLUME control on the I21.
The TAPE OUT sockets provide a xed level copy of the
currently selected source, suitable for connecting to a tape
Connect each source to the appropriate source input,
connecting the right channel to the red socket and the left
channel to the white socket.
To connect an analogue turntable with a moving mag-
net or moving coil cartridge you will need an additional
phono preampli er such as the Primare R20. The output
of the turntable is connected to the R20, and the output
of the R20 should be connected to a spare input on the
