Primare I21 - Using the I21 with Other Primare Products; Technical Specification

2
I21 AMPLIFIER USER GUIDE
INTRODUCTION
Using the I21 with other Primare
products
Although the I21 is  exible enough to work with virtu-
ally any other equipment
you have in your system, it is
ideal for use with the other products in the Primare range.
A particular bene t of using the I21 with other Primare
sources is that you can control your entire system with a
single remote control, to give you a fully integrated system
with the simplest possible user interface.
Technical speci cation
Output power per channel
2 x 75W into 8
Ω
,
2 x 125W into 4
Ω
Speaker terminals
4 –16
Ω
Output impedance
<0.08
DC offset
<5mV (servo controlled)
Line inputs
330mV
Tape outputs
300mV
Frequency response
<10Hz – 100kHz, -3dB
THD
0.05% (1kHz, 10V into 8
Ω
)
Signal-to-noise, line
-100dB (A-weighted)
Power consumption, standby
<12W
Peak current
±
25A
Dimensions (WxDxH)
430 x 385 x 100mm
Weight
13,5kg
