6 Assembly
WARNING
Danger of injuries
An improper assembly by inexperienced personnel can lead to material
damages or even personal injuries.
Read and strictly observe the safety instructions in chapter „1 Basic
Safety Instructions“ on page 5.
6.1 Assembly Position
The PocketMonitor can be assembled in any position. However, the absorber has to be
thermally insulated in order to ensure that no heat can dissipate, and the measuring
result is not distorted.
6.2 Integration into a Laser System
1. First, the laser source has to be turned o.
2. Ensure that all moving parts, e.g. robot arms etc., must be at a standstill, and that
they cannot be set in motion unintentionally.
3. Stability: When mounting the device, please ensure that a relative movement towards
the beam axis is prevented which in turn reduces the risk of scattered radiation.
WARNING
Danger of injuries
If the measuring device is moved out of the measured position, scattered
radiation is increasingly caused during the measurement operation.
When mounting the device, please ensure that it cannot be moved by
unintentional impacts or vibrations.
4. Heat insulation: When assembling the device, please ensure that no absorber heat
is lost during the measurement. Otherwise, the display values are too low. Put heat
insulating and temperature resistant material underneath the device.
