35,0(6
PocketMonitor PMT
3
Revision 01/2017 EN
Contents
1 Basic Safety Instructions 5
2 Symbol Explanation 7
3 Conditions at the Installation Site 9
4 System Description 9
4.1 Measuring Principle .......................................................................................................... 10
5 Transportation 10
6 Assembly 11
6.1 Assembly Position.............................................................................................................. 11
6.2 Integration into a Laser System .................................................................................... 11
6.3 Removal from the Laser System ................................................................................... 12
7 Operating Buttons 13
8 Display 14
9 Measuring 15
9.1 Measurement Preparation .............................................................................................. 16
9.1.1 Getting the Device Ready for Operation ...................................................................16
9.2 Requirements for Accurate Measuring Results ....................................................... 16
9.3 Single Measurement ......................................................................................................... 18
9.4 Repetitive Measurement .................................................................................................20
9.5 Possible Errors ..................................................................................................................... 21
10 Maintenance 22
10.1 Exchanging the Battery ................................................................................................... 22
11 PMT with a Separate Absorber (OPTION) 22
12 Current Loop Interface (OPTION) 23
13 Measures for the Product Disposal 25
