Primus FX80 - Technical Problem Diagnosis

14 INSTALLATION, MAINTENANCE AND USER' MANUAL 540889_PUB_DATE_1_JUL_2011.DOC
Operation
First service at technical problem
N° Failure message Failure Action Fault occurrence
E2
No Drain
Drain failure Full Stop + tumble Draining sequence
E3
Tilt Fault
Out of balance Full stop + tumble Whole cycle
E4
Imbalance
Out of balance : Normal
spin
Skip + continue After 5 attempts to spin
E5
Tilt High Sp
Out of balance : high
spin
Full stop + safety time >500 or 750 RPM
E6
Door Coil
Door switch failure Full stop + safety time Whole cycle
E7
Door Switch
Door solenoid switch
failure
Full stop + safety time Whole cycle
E8
Door Start
Door lock check at start
failure
Don’t start At start up
E9
Door Unload
Door lock switch closed
failure
Don’t start End cycle
E11
No Fill
Fill failure
Full stop + request for
Continue
While filling
E12
Overfill
Overfill failure Full stop + tumble While filling
E13
No Heating
Heating failure Full stop + tumble While heating
E14
Heat Time
Heating time failure
Full stop + request for
Continue
While heating
E15
Too Hot
Too Hot Full stop + tumble While heating
E21
Overflow
Overflow failure Full stop + tumble Wash step
E24
Level Sens
Defective level sensor Continue + Don’t start Before start up
E25
Temp Sensor
Defective temperature
sensor
Continue + Don’t start Before start up
E26
Mitsub code
Undefined frequency
inverter error code
Full stop + tumble Whole cycle
E27
Comm fault
Communication fault
inverter
Full stop + safety time Whole cycle
E28
THT time / E.OL
THT Time out / E.OL Full stop + safety time At spin sequence
E29
OV3 time / E.OP
OV3 Time out / E.OP Full stop + safety time At spin sequence
E31
Load Parr
Initialization fault
inverter
Don’t start At initialization
E32
Verify Parr
Verification fault
inverter
Don’t start At loading parameters
E35
Wrong Softw
Wrong software version Don’t start New software version
E37
No Drain Sp
Drain failure at the
Spray Sequence
Full stop + tumble Spray Sequence
E39
Out of Soap
The Soap Supplies are
running Out of Soap
For Info only Wash step
E41
Service Due
Service Due Warning
For Info only
Open door = reset
End cycle
E42
Connection
No Network
Connection
For Info only Data Transfer Networking
