100962 G PUBLICATION DATE 24 JUN 2008.DOC PROGRAMMING MANUAL 65
↵
configuration menu is enabled. Extra supplies, correspond
with soap pump signals.
• The Spray Sequence will only function with 1 Supply.
If you have programmed more then 1 supply an error
message will be generated. Put the time of the supplies back
to zero until not more then 1 non-zero time value is
remaining.
• If a supply has been programmed, no spray inlets can be
programmed.
• The supplies can be programmed for an interval time
between 0 and 99 seconds.
• The supply will not be activated if 0 Seconds is programmed.
• The overview display shows the Supply Name and the
corresponding programmed time.
• If No supply has been programmed : the Spray sequence will
not be functional (the sequence time must also be 0)
(cfr No Wash).
• Insert the desired supply time. Press the ENTER
button for confirmation.
• At the end of the Menu, when EXIT is displayed, you have to
press the ENTER button to leave the supply Menu.
Attention
!
For Front Soap Hopper washing machines, the soap is
added by programming the supplies A to E. (X22/5 A to D)
External liquid soap pumps correspond with the supplies
F to K.
For Top Soap Hopper washing machines, the External liquid
soap pumps correspond with the supplies D to J.
The number of external supplies that is available depends
on the machine type.
X & XF - Type machines Only
• Spray 1 : cold water
• Spray 2 : warm water
• The Spray Inlet will be open for the programmed time.
• Yes : Spray inlet enabled.
No : Spray inlet disabled.
• Press the ENTER button for confirmation.
X & XF - Type machines Only
• The Step Time can only be inserted when no supply has
been programmed.
• The Spray Sequence can be programmed between 0 and 99
P:Pr XX Step XX
Supply A : 0 Sec
P:Pr XX Step XX
Spray 1 : No
P:Pr XX Step XX
Time : 1.0 Min
P:Soap Supply
Menu Exit
P:Pr XX Step XX
Spray 2 : No
!
To Next Page
