Pro-face GP-3500L - And Gp-4501 T

Chapter 1 Specification Comparison
1.1 Specifications of GP-3500S and GP-4501T
GP-3500S GP-4501T
Display Type STN color LCD UP! TFT Color LCD
Display Colors 4,096 colors
UP!
65,536 colors (without blink)/
16,384 colors (with blink)
Display Resolution VGA (640×480 pixels)
Panel Cutout
Dimensions (mm)
301.5(W)×227.5(H)
259(W)×201(H)
→See 2.4
External Dimensions
(mm)
313(W)×239(H)×56(D) 272.5(W)×214.5(H)×57(D)
Touch Panel Type Analog
Analog/Matrix →See 2.2
Application 8MB/ 16MB UP! 32MB
Memory
SRAM 320KB 320KB
Backup Battery
Secondary Battery
(Rechargeable Lithium
battery)
NEW!
Primary Battery (Replaceable
Lithium battery)
→See 2.9
Rated Input Voltage AC 100 to 240V/ DC 24V
COM1
D-Sub 9 pin (plug)
RS-232C/422/485
D-Sub 9 pin (plug)
RS-232C
→See 2.6.1
Serial
I/F
COM2
D-Sub 9 pin (socket)
RS-422/485
D-Sub 9 pin (plug)
RS-422/485
→See 2.6.1
Ethernet I/F 10BASE-T/100BASE-TX
CF Card I/F
✔
- →See 2.6.4
6/49
