1.2 Specifications of GP-3500S and GP-4501TW
GP-3500S GP-4501TW
Display Type STN color LCD UP! TFT Color LCD
Display Colors 4,096 colors
UP!
65,536 colors (without blink)/
16,384 colors (with blink)
Display Resolution VGA (640×480 pixels)
Panel Cutout
Dimensions (mm)
301.5(W)×227.5(H)
External
Dimensions (mm)
313(W)×239(H)×56(D) 315(W)×241(H)×56(D)
Touch Panel Type Analog
Application 8MB/ 16MB 16MB
Memory
SRAM 320KB 128KB
Backup Battery
Secondary Battery
(Rechargeable Lithium
battery)
NEW!
Primary Battery
(Replaceable Lithium battery)
→See 2.9
Rated Input Voltage AC 100 to 240V/ DC 24V
DC 24V →See 2.8
COM1
D-Sub 9 pin (plug)
RS-232C/422/485
D-Sub 9 pin (plug)
RS-232C
→See 2.6.1
Serial
I/F
COM2
D-Sub 9 pin (socket)
RS-422/485
D-Sub 9 pin (plug)
RS-422/485
→See 2.6.1
Ethernet I/F 10BASE-T/100BASE-TX
CF Card I/F
✔
- →See 2.6.4
SD Card I/F -
NEW! ✔
