Pro-Form 10.0 Ze Elliptical User Manual

11
10. Untie and discard the wire tie attached to the
Wire Harness (60).
W
hile a second person holds the Console (33)
near the Upright (5), connect the wires on the
C
onsole to the Wire Harness (60) and to the
Pulse Wires (34).
Insert the excess wire into the Console (33) or
the Upright (5).
Tip: Avoid pinching the wires. Attach the
Console (33) to the Upright (5) with four M4 x
16mm Screws (93).
10
11
11. Attach the Rear Upright Cover (24) to the
Upright (5) with two M4 x 16mm Screws (93)
and an M4 x 19mm Flat Head Screw (117).
3
3
34
60
93
93
117
24
5
5
A
void pinching
the wires

Pro-Form 10.0 Ze Elliptical Specifications

General

Brand	Pro-Form
Model	10.0 Ze Elliptical
Category	Elliptical Trainer
Language	English
