12
13. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plas-
ticonthetreadmilldecals,removetheplastic.Toprotecttheoororcarpet,placeamatunderthetreadmill.
Note: Extra hardware may be included. Keep the included hex keys in a secure place; one of the hex keys is
used to adjust the walking belt (see pages 23 and 24).
12. Attach the Latch Housing (67) to the Left Upright
(66) with two #10 x 1/2" Screws (86); make
sure that the knob is on the indicated side.
Start both Screws, and then tighten them. Be
careful not to overtighten the Screws.
Knob
12
67
66
86
11. Slide the Right Upright Cover (89) up against
the Right Handrail (64). Attach the Right Upright
Cover with two M4.2 x 16mm Screws (56). Be
careful not to overtighten the Screws.
Attach the Left Upright Cover (not shown) as de-
scribed above.
See steps 4 and 5. Tighten the six 3/8" x 3 1/4"
Screws (2).
56
89
64
11
