4. Attach the four Base Pads (81) to the base of the Uprights
(85) in the indicated locations with four 1” Tek Screws
(82) and four Plastic Spacers (101). Note: One replace-
ment Base Pad may be included. Use the Base Pad to re-
place any Base Pad that becomes worn.
With the help of a second person, carefully tip the tread-
mill down so the four Base Pads (81) are resting on the
floor and the Uprights (85) are in the vertical position.
85
82
81
101
101
101
101
82
55
81
2. With the help of a second person, set the console assem-
bly on the Uprights (85). Make sure that no wires are
p
inched. A
ttach the console assembly with four Console
Bolts (72), four Washers (96), and four Star Washers (67)
(
only one side is shown).
S
tart all four Console Bolts
before tightening any of them.
96
72
67
8
5
96
67
C
onsole
A
ssembly
4
2
3. With the help of a second person, carefully tip the tread-
mill onto its side as shown.
Insert an Extension Leg (97) into the indicated bracket
on the base of the Uprights (85).
Make sure that the
Extension Leg is turned so the Base Pad (81) is on
the side shown. If necessary, use a rubber mallet to
align the holes in the Extension Leg with the holes in the
bracket.
Attach the Extension Leg (97) with two Extension Leg
Bolts (87), two Washers (96), and two Nuts (106) as
shown. Firmly tighten the Nuts.
With the help of a second person, carefully tip the tread-
mill onto its other side. Attach the other Extension Leg
(not shown) as described above.
85
Bracket
97
3
106
87
96
81
To Next Page
