Note: The assembly procedure is divided into four stages: 1) frame
assembly, 2) arm assembly, 3) cable assembly, and 4) seat assembly.
The hardware for each stage is packaged separately. WAIT UNTIL YOU
BEGIN EACH ASSEMBLY STAGE TO OPEN THE PARTS BAG LABELED
FOR THAT ASSEMBLY STAGE.
This chart is provided to help you identify the small parts used in assembly. The number in parenthesis following
each part description refers to the key number of the part. Important: Some parts may have been pre-assem-
bled for shipping purposes. If you cannot find a part in the parts bags, check to see if it has been pre-
assembled.
REMOVE THIS PART IDENTIFICATION
CHART FROM THE MANUAL
To Next Page
