9
15. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
14
14. Identify the Left Pedal (26), which is marked with an
“L.” Using an adjustable wrench, firmly tighten the
Left Pedal counterclockwise into the left arm of the
Crank (18). Tighten the Right Pedal (not shown)
c
lockwise into the right arm of the Crank. Important:
Tighten both Pedals as firmly as possible. After
using the exercise cycle for one week, retighten
the Pedals. For best performance, the Pedals must
be kept tightened.
Adjust the strap on the Left Pedal (26) to the desired
position, and press the end of the strap onto the tab
on the Left Pedal. Adjust the right pedal strap in the
same way.
26
Strap
Tab
18
To Next Page
