6
M10 x 65mm Screw (40)–4
M10 x 60mm Bolt (61)–1
M10 x 54mm Screw (97)–1
M8 Locknut
(10)–10
M10 Locknut
(48)–1
M6 Locknut
(51)–4
M8 x 125mm Bolt (58)–2
M8 Split
Washer
(42)–8
M6 Curved
Washer
(25)–4
M10 Curved
Washer (39)–3
M8 Large
Washer (54)–4
Wave Washer
(81)–4
M8 Small
Washer
(93)–4
M8 x 40mm Bolt (83)–6 M8 x 65mm Bolt (94)–2
M8 x 20mm
Screw (34)–4
M4 x 16mm
Screw (47)–8
M6 x 30mm
Bolt (49)–4
M8 x 13mm
Screw (95)–6
M10 x 25mm
Screw (96)–1
M10 Split
Washer (98)–2
#8 x 12mm
Screw (102)–4
PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
