11
11
23
23
23
23
23
41
41
41
4
8
10
10
10
12
29
1
1
11. Insert a Pad Tube (10) into the Front Leg (8).
Next, slide a Foam Pad (23) onto each side of
the Pad Tube, and then press a Pad Cap (41)
into each end of the Pad Tube.
Attach the other Pad Tubes (10), Foam Pads
(23), and Pad Caps (41) to the Leg Lever (4) in
the same way.
Note: There are two holes near the lower end of
the Leg Lever (4). Use the hole that positions the
Foam Pads (23) at the most comfortable height.
41
12. Fully insert the Weight Rests (29) and the
Spotters (24) into the desired adjustment holes
in the Uprights (1). Make sure that the Weight
Rests are at the same height and that the
Spotters are at the same height.
24
29
24
To Next Page
