11
8. See the inset drawing. Connect the connector
on the Upper Wire (56) to the connector on the
Lower Wire (82).
Next, tighten the zip tie (C) around the indicated
mark (D) on the Upper Wire (56). Then, cut off
the excess zip tie.
8
56
82
C
D
56
82
9
9. Tip: Avoid pinching the wires. Press the Motor
Cover (38) onto the Frame (1), and then attach it
with an M4 x 20mm Screw (81).
81
38
1
Avoid
pinching
the wires
C
