10
7. Insert the Upright Wire (70) into the Left Upright
(75) as you set the console assembly on the Left
Handrail (71) and the Right Handrail (72). Make
sure that no wires are pinched.
Attach the console assembly to the Left and
Right Handrails (71, 72) with two 5/16" x 1" Bolts
(7) and two 5/16" Star Washers (8). Start both
Bolts before tightening them.
72
71
8
8
7
7
7
Console
Assembly
Console
Assembly
Wire
Tie
70
6
70
75
Console
Wire
6. With the help of a second person, hold the con-
sole assembly near the Left Upright (75).
Connect the Upright Wire (70) to the console
wire. See the inset drawing. The connectors
should slide together easily and snap into
place. If they do not, turn one connector and try
again. IF YOU DO NOT CONNECT THE CON-
NECTORS PROPERLY, THE CONSOLE MAY
BECOME DAMAGED WHEN YOU TURN ON
THE POWER.
Remove the wire tie from the Upright Wire (70).
Console
Wire
70
75
To Next Page
