9
5
. Set the Console (103) on the handrail assembly.
Be careful not to pinch the wires.
Attach the Console (103) on the handrail assem-
bly with two 3/8" x 1 3/4" Patch Bolts (3) and two
3/8" Star Washers (4). Start both Patch Bolts
b
efore tightening either of them.
5
6. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of clear
plastic on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the tread-
mill. Note: Extra hardware may be included. Keep the included hex keys in a secure place; one of the hex
keys is used to adjust the walking belt (see pages 19 and 20).
103
3
Handrail
Assembly
4
3
4
