13
HOW TO MOVE THE ROWER IN THE FOLDED
POSITION
Take any necessary measures to protect your floor.
See HOW TO FOLD AND STORE THE ROWER at the
right, and fold the rower. Then, hold the Frame Handle
(H), place your foot on a Stabilizer Foot (I), and tip the
rower until it will roll on the wheels. Carefully move the
rower to the desired location, and then tip it into the
storage position. Do not hold or pull on the console
when moving the rower.
HOW TO FOLD AND STORE THE ROWER
The rower can be stored in a folded position to con-
serve space. Store the rower in a location where
children cannot tip it. Unplug the power adapter
when storing the rower for extended periods of time.
To store the rower, first slide the Seat (J) to the rear of
the Rail (G).
Next, hold and lift the Frame Handle (H) and the Rail
Handle (K), and tip the rower forward onto the Shields
(L, M) and the Storage Feet (N) (see the drawing on
page 14).
H
I
J
G
K
H
O
N
L, M
