8
9. Attach the Seat (14) to the Seat Carriage (3) with four
M6 x 20mm Button Screws (52). Note: The Button
Screws may be preattached to the underside of the
Seat.
10. Attach the Backrest (15) to the Backrest Bracket (13)
with four M6 x 38mm Button Screws (46). Note: The
Button Screws may be preattached to the Backrest.
9
10
3
13
14
15
46
46
52
52
52
To Next Page
