12
15. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
13. Plug the Pulse Wire (38) into the Pulse
Receptacle (39) in the Frame (1).
13
14. Identify the Right Pedal (44), which is marked
with an “R.” Using an adjustable wrench, firmly
tighten the Right Pedal clockwise into the right
side of the Crank (17). Tighten the Left Pedal
(not shown) counterclockwise into the left side
of the Crank. IMPORTANT: Tighten both
Pedals as firmly as possible. After using the
exercise cycle for one week, retighten the
Pedals.
Adjust the strap on the Right Pedal (44) to the
desired position, and press the ends of the
straps onto the tabs on the Right Pedal. Adjust
the strap on the Left Pedal (not shown) in
the same way.
14
38
44
17
39
1
Strap
Tab
To Next Page
